6S 12A Lithium-ion Battery 18650 BMS Protection Board

6S 12A Lithium-ion Battery 18650 BMS Protection Board

Description A 6S 12A circuit power tool known as the BMS 6S 12A 18650 Lithium-ion Battery Protection Board is mainly used for solar illumination for dedicated 18650 battery packs. It...
23 people are viewing this right now

AvailabilityIn stock

Ask For Price
SKU: ATC-2574
Vendor: ArrowTechCart

Shipping & Returns

Free shipping and returns available on all orders!

We ship all orders within 5-10 business days

Care Instructions

We advise routinely dusting your items with a gentle cleanser to preserve its look. Periodically, it may need to be softly wet with a mild detergent solution.

Collections: BMS
View full product details

Description

A 6S 12A circuit power tool known as the BMS 6S 12A 18650 Lithium-ion Battery Protection Board is mainly used for solar illumination for dedicated 18650 battery packs. It is made for 3.7V 18650 lithium batteries for charging and overcharge and over-discharge protection. As the name implies, a battery protection board primarily safeguards an integrated circuit board and is rechargeable. Rechargeable lithium batteries require protection, which is based on their unique properties. Lithium battery components always adhere to a protective plate with a sampling resistor, a current fuse, and a current limiter because the material of the lithium battery prevents it from being overcharged, over-discharged, overcurrent, shorted out, and charged and discharged at extremely high temperatures.

APPLICATIONS

  1. Battery pack
  2. Power supply
  3. Power bank and charger

FEATURES

  1. This protection board is suitable for six series Li-ion cells.
  2. Adopt a precision integrated circuit for fast and safe charging.
  3. Support overcharge protection, over-discharge protection, and short circuit protection.
  4. This product has gone through a load and ageing test for quality assurance.
SPECIFICATIONS
Battery 6 Cell
Overcharge Detection Voltage 4.25 ± 0.025V
Over-discharge Detection Voltage 2.50 ± 0.08V
Overcurrent Protection 50A
Working current 12A
Operating Temperature -40~+85°C
Short circuit protection Yes
Length 50mm
Width 32mm
Height 4mm
Weight 6gm
