ACS712 - 5A Range Current Sensor Module

ACS712 - 5A Range Current Sensor Module

Regular price ₹ 120.00
Regular price ₹ 150.00 Sale price ₹ 120.00
Sold Out
Tax included. Shipping calculated at checkout.
Description The 5A ACS712 range Current Sensor Module consists of a precise, low-offset, linear Hall circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction...
22 people are viewing this right now

AvailabilityIn stock

SKU: ATC-4674
Vendor: ArrowTechCart

Shipping & Returns

Free shipping and returns available on all orders!

We ship all orders within 5-10 business days

Care Instructions

We advise routinely dusting your items with a gentle cleanser to preserve its look. Periodically, it may need to be softly wet with a mild detergent solution.

View full product details

Description

The 5A ACS712 range Current Sensor Module consists of a precise, low-offset, linear Hall circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field in which the Hall IC converts into a proportional voltage.

Sensing and controlling current flow is a fundamental requirement in a wide variety of applications including, over-current protection circuits, battery chargers, switching mode power supplies, digital watt meters, programmable current sources, etc.

Connection Diagram



Interfacing a current sensor with Arduino uno

Current Sensor Connection With Arduino

The curve of relation between the DC input voltage and measuring current:

read our blog explaining  Interfacing ACS712 current sensor with Arduino, which provides information about the ACS712 current sensor, discussing its features, working principle, hardware requirements, and applications.

Specification

  • 185 mV/A output sensitivity
  • 5.0 V, single-supply operation
  • Output voltage proportional to AC or DC currents
  • Factory-trimmed for accuracy
  • Extremely stable output offset voltage
  • Nearly zero magnetic hysteresis
  • Analog Output so can be easily connected to any Microcontroller
