Description :-

ESPRESSIF ESP32-WROOM-32 MCU Modules are powerful and generic Wi-Fi/BT/BLE MCU modules that target a wide variety of applications. These modules target applications ranging from low-power sensor networks to the most demanding tasks, such as voice encoding, music streaming, and MP3 decoding. The ESP32-WROOM-32U module is different from ESP32-WROOM-32D as it integrates a U.FL connector which needs to be connected to an external IPEX antenna. The ESP32-WROOM-32 MCU Modules use the ESP32-D0WD chip at their core. This SoC features two CPU cores that can be individually controlled, and the CPU clock frequency is adjustable from 80 MHz to 240 MHz. The ESP32 integrates a rich set of peripherals, ranging from capacitive touch sensors, Hall sensors, SD card interface, Ethernet, high-speed SPI, UART, I2S, and I2C. This is a family of ESP32-based modules with some integrated key components, including a crystal oscillator and an antenna matching circuit. The modules constitute ready-made solutions for integration into final products. If combined with a few extra components, such as a programming interface, bootstrapping resistors, and pin headers, these modules can also be used for the evaluation of ESP32’s functionality.

Features:-

• It is a dual-core processor.
• CPU clock frequency is adjustable from 80 MHz to 240 MHz.

• CPU cores that can be individually controlled.

• It operates between 2.7V and 3.6V.

Specification :-

• Operating voltage supply :- 2.7 V - 3.6 V

• Average operating current :- 80 mA

• Sensor type :- Hall sensor

• Bluetooth :- v4.2 BR/EDR and BLE

• Operating temperature range :- -40 °C - 85 °C

• No. of Pins :- 30

*Note: Product Image are shown for illustrative purposes only and may different from the actual product
