TS-300B Water Turbidity Sensor With Connector Cable

TS-300B Water Turbidity Sensor With Connector Cable

Description Its a turbidity sensor its used to sense the particles in water. Its used to measure and the detect of the liquid particles in water like Suspended particles, Dirt,...
17 people are viewing this right now

AvailabilityIn stock

Ask For Price
SKU: ATC-2760
Vendor: ArrowTechCart

Shipping & Returns

Free shipping and returns available on all orders!

We ship all orders within 5-10 business days

Care Instructions

We advise routinely dusting your items with a gentle cleanser to preserve its look. Periodically, it may need to be softly wet with a mild detergent solution.

Collections: Water Sensor
View full product details

Description

Its a turbidity sensor its used to sense the particles in water. Its used to measure and the detect of the liquid particles in water like Suspended particles, Dirt, Dust, Algae etc. Its works by the shining of the light when light falls on water and if there is any suspended particle in the water then the particle will absorb/Scattered more lights in compare to water molecules by this it calculate the turbidity of water. It has female to female Connector Wire By which we can connect it to the microcontroller Board. Its version is 2.0_1227K.

Features:

  • Its colour is Sky-Blue and White
  • Its operating Voltage is 3.3-5VDC
  • Its measuring Range is 0-1000NTU
  • AO: analog signal output, output voltage range 0~5V
  • DO: digital signal output is less than the set value and outputs high level; greater than the set value and outputs low level
  • GND: negative supply voltage
SPECIFICATION
Model TS-300B
Length of The Wire 20cm
Working Voltage 5V
Working Current  40mA
Response Time 500mS
Insulation Resistance 100MOhm
Operating temperature -20℃~90℃
Dimensions 35mmx34mm
Colour Sky-Blue and White
